23ZERO Kabari XL & 3.0 Extended Window Pole Mounts

The Extended Window Pole Mounts (4) provide easy-access attachment points for the poles that support the tent’s window overhangs. These mounts are essential when an awning or similar shelter is installed, as the original attachment points may no longer be accessible.

Extended Window Pole Mounts Key Features

• Custom-fit: These custom brackets match the extrusion profile of the Kabari XL & Kabari 3.0 tents
• Secure window overhang support: Provides easy access attachment points
• Quick and easy mounting: Attaches to the tent’s upper side rail using T-nuts and bolts
• Drip guard design poles: 35.75 inch support poles with keyed ends and bends to channel water away

Extended Window Pole Mounts Specifications

• Four (4) angled brackets: 3.75 W x 5.675 H inches
• Four (4) pole attachment fittings: 3.75 W x 1.125 L x 0.9375 H inches
• Four (4) support poles: 35.75 inches long
• Four (4) Spacer plates: 3.75 W x 0.75 H (optional use)
• Hardware kit includes:
  • 16 M8 x 1.25 x 0.5-inch bolts
  • 8 T-nuts
  • 8 Nylock nuts
